bow screen filtration product
Filtration Products

Bow Screen

Dewatering and removal of substances in process water and industrial wastewater

  • Dewaterer

  • Self-cleaning
  • No moving parts

Bow Screens are used to dewater reject water from wastewater treatment plants, screening, thickening and dewatering of e.g. paper mill backwater.

Inquiry
Specs

Specs

Capacity

3 – 300 m³/h

Slot Width

0,25 – 1,0 mm

Connectivity Dimensions

DN50 – DN300

Materials

Stainless Steel EN1.4301 / EN1.4404 / EN1.4436

Features

Features

The separated material is gradually fed downwards onto the top of the screen where it is dewatered and finally falls over the bottom edge. The separated material is preferably collected in a container or on a conveyor belt. The screened water flowing down through the slits of the screen surface is collected in the bottom of the container for further transport out through the outlet, which can optionally be located at the bottom of the container, at the back or at the gable end.

Model BG

  • Operates without pressure

  • The water spreads over from the inlet box and further out over the screen surface

  • Six available sizes

Model BP

  • Requires a supply pressure of 1 to 2 bar

  • The water is distributed over the screen surface with pressure via nozzles
  • Three available sizes

Model BP

  • Requires a supply pressure of 1 to 2 bar

  • The water is distributed over the screen surface with pressure via nozzles
  • Three available sizes
